Physical ………… 2 Gigabit ports (up to 8 ports supported)
Access ……………..……..…… MMS, RTSP, ShoutCast, IcyCast
Transport …………….……………………………… ASF, Real, ADTS
Codec………………… MPEG-2/MP3/AAC/AACP/REAL/WMV
Physical ……….… 2 Gigabit ports (up to 8 ports supported)
Transport ……….……………………..…… MPTS/UDP, SPTS/UDP
Codec……………………..………….… MPEG Layer II/AAC/V1/V2
Sample Rates …………..…… 24KHz, 32Khz, 44.1 KHz, 48Khz
Channels …………….…………..……………………… Mono, Stereo
Level ……………..………………… Adjustable gain (-20…+20db)
Rate Control …………..……………….………… CBR, capped VBR
Bitrates………..…24,32,48,64,92,128,160,192,256,324 kbps
3 sources per channel, hot-swapped upon source failure
User defined source timeout definitions
User defined connection retries
SNMP ….…………………… Configurable SNMP TRAPS V1/2
SMNP Type …………….….………………… RFC1213, RFC1215
SYS LOG ………………….… Configurable sys-log notifications
SMTP …………………………………..………….. Email notifications
Web ….…….………..……….. Complete configuration via web
Remote …….……………………………………. JSON WEB services
CLI ……………………….. Network & software management
Software upgrade…………………… via FTP & CLI interface
Absolutely! Did you know all our existing clients tried the system before choosing TAG? (Okay, all but one). Apply for your free 90 day trial: https://www.tagvs.com/tag-trial/
The TAG platform has an elaborated JSON API which can be used by custom user panels configured to control the system functionalities.
Input:
HEVC, MPEG-2, H.264, ZIXI, JPEG-2K, JPEG-XS, ST 2110 / -7, ST 2022-6 / -7, DASH, HLS, TS/UDP, TS/RTP, HLS, DASH, RTMP, UHD, HD, HDR, DOLBY-D, ATMOS, AAC, M2A, A52, AES67
Output:
ST 2110 / -7, ST 2022-6 / -7, H.264, ZIXI, SPTS, HLS, HD, UHD
Yes! The TAG open, flexible and rich APIs allow integrations with virtually any system
Absolutely- You can view all monitored streams in the same layout.
